PET Expandable Braided Sleeving
- Part No: BS-PET
- Material: Polyester
- Standard Color: Black
- Sizes: Flat width 3mm~80mm, special sizes can be customized
- Operating range: -50℃±150℃
- Melt point: 240℃±10℃
- Flammability: VW-1
- Cutting tool : Hot knife
- Feature: Flame retardant, wear-resistant, expandable, odorless, halogen-free, environmentally friendly and harmless, etc
- MOQ: 500m
- Sample: Free sample
PRODUCT DESCRIPTION
PET expandable braided sleeving is a high-performance telescopic cable sleeve which is flame-retardant and halogen-free.
It can meet the requirements of various industrial fields, especially wear-resistant protection.
Its unique braided structure can be expanded to 1.5 times the original diameter, making it more suitable for wrapping wire harnesses and can pass through large connectors smoothly.
APPLICATION SCENARION
PET expandable braided sleeving can be used in a wide range of applications in automotive, electronic, industrial, data fiber, and marine industries. It can also be used for wire protection of computers, televisions and other appliances in homes & offices.
This PET expandable braided sleeving is easy to cut with a hot knife. Easy installation, wear-resistant, noise reduction, cost-effective, can be a good protection of various industrial & household wires.
Color Customization
The standard color for our PET expandable braided sleeving is black, not only in a single color, but also in a variety of colors, which can be customized according to customer needs
Specification
| Flat Width (W) | Part No. | Expanded Range (mm) | Packing (L) | |
| mm | Min.(I) | Max.(O) | ||
| 3 | BS-PET003 | 1 | 4 | 500m/roll |
| 6 | BS-PET006 | 3 | 6 | 500m/roll |
| 8 | BS-PET008 | 5 | 7 | 500m/roll |
| 10 | BS-PET010 | 7 | 15 | 500m/roll |
| 12 | BS-PET012 | 8 | 20 | 500m/roll |
| 15 | BS-PET015 | 10 | 22 | 250m/roll |
| 20 | BS-PET020 | 14 | 26 | 250m/roll |
| 25 | BS-PET025 | 16 | 30 | 100m/roll |
| 30 | BS-PET030 | 20 | 40 | 100m/roll |
| 35 | BS-PET035 | 22 | 45 | 100m/roll |
| 40 | BS-PET040 | 25 | 50 | 100m/roll |
| 45 | BS-PET045 | 30 | 60 | 100m/roll |
| 50 | BS-PET050 | 40 | 70 | 100m/roll |
| 60 | BS-PET060 | 45 | 80 | 100m/roll |
| 70 | BS-PET070 | 50 | 90 | 50m/roll |
| 70 | BS-PET070 | 55 | 110 | 50m/roll |
- Nominal size indicates the flat width.
2. This kind of cable sleeve has expandable character, each size will have deviation, and the expanded range is for reference only.
Package Customized
1. Standard package-Reel packing
2. Small-sized box packaging
3. PE ziplock bags
4. PVC boxes, etc.
No matter what the packaging, we can print the customer’s logo, product information, contact information, etc., on the outer packaging according to the customer’s needs.
Why choose us
EKO & QX cable sleeve company is is a manufacturer with independent development of cable management sleeves, whether you are a brand owner, retailer, and wholesaler, offline physical store, or online Amazon, AliExpress, and other platforms, we can provide one-stop cable sleeve customization services.
It covers special customization, packaging customization, logo printing, etc. to meet the diversified needs of customers and provide the best solution.
Product Customized
We design and develop new products according to our customer’s style requirements and engineering needs.For example, we develop special PET and zipper cable management styles according to customer needs, etc.
Special technique
If the projects need special environments requirements, there are special process treatments that could be met, such as UV resistance, low-smoke halogen-free, flame retardant and so on.
Logo customized
We customize packaging with customer logos, product details, and specifications, facilitating easy identification and use upon delivery. This also aids customer promotion in local markets.
Service Advantage
With over 19 years of OEM and ODM expertise, we offer professional technical support and tailored solutions for cable sleeve needs.
PET Expanble Braided Sleeve Application Case
PET Expandable Braided Sleeve for Bicycle Lock
A customer used our 38mm × 0.3mm PET expandable braided sleeve to create a lightweight, flexible bicycle lock.
Thanks to the sleeve’s expandable and durable structure, the lock becomes:
- More flexible to wrap around posts, fences, and irregular objects
- Lighter and easier to carry, fitting on bikes or backpacks
- Still highly protective, resisting common theft tools
This case shows how PET expandable sleeving is widely used beyond cables such as fishing rods, pet leashes, toys, and innovative custom products.
PET Expandable Braided Sleeve for PC Cable Management
In this case, PET expandable braided sleeving is used for professional PC cable management. The sleeving bundles and protects power cables & fan wires, giving the build a cleaner.
Key Benefits:
- Neat cable routing inside gaming & workstation PCs
- Abrasion protection for cables near sharp metal edges
- Flexible, expandable weave makes it easy to install over multi-cable groups and connectors
This example shows how PET braided sleeving is widely used in PC assembly, modding, DIY builds, and server systems to enhance both protection and aesthetics.
